Liquid/Paste Filling Equipment

Pneumatic Piston Filler


Piston filling machines are specifically designed to allow for accurate fill volumes of both thick and thin products. Products that contain chunks, such as salsas, tomato sauces and other products with particulates can also be filled using a piston filler.

Our superior piston filler machine also improves production speed. Liquid filling machines are one of the most critical food packing machines in a facility, especially for bottle fillers. If a filling machine lags, then the whole production line slows down. Investing in a more advanced filler machine allows the entire production process to be modernized and speed up.

Get precision, speed, and control with our pneumatic piston filler!


PPF120

Pneumatic Filler
Item P/N: PPF120
Available Range Paste Liquid
Features Heavy duty stainless steel construction, Clean Room compatible
Filling Range Cream 10-120ml
Liquid 10-108ml
Filling Accuracy Cream ±2%
Liquid ±1%
Working Air Pressure 0.4-0.5MPa
Throughput 0-30 bottles/minute
Outline (length x width x height) 50" x 13" x 27.5"
Net Weight 82.5 lbs (37.5kg)

Price:
List Price: $3,891.60
Prepaid Price: $3,450.00


PPF500

Pneumatic Filler
Item P/N: PPF500
Available Range Paste Liquid
Features Heavy duty stainless steel construction, Clean Room compatible
Filling Range Cream 50-500ml
Liquid 45-450ml
Filling Accuracy Cream ±2%
Liquid ±1%
Working Air Pressure 0.4-0.5MPa
Throughput 0-30 bottles/minute
Outline (length x width x height) 50" x 13" x 27.5"
Net Weight 80 lbs (37.5kg)

Price:
List Price: $4,134.12
Prepaid Price: $3,665.00



Call for Pricing and Availability


PPF1000

Pneumatic Filler
Item P/N: PPF1000
Available Range Paste Liquid
Features Heavy duty stainless steel construction, Clean Room compatible
Filling Range Cream 100-1000ml
Liquid 90-900ml
Filling Accuracy Cream ±2%
Liquid ±1%
Working Air Pressure 0.4-0.5MPa
Throughput 0-30 bottles/minute
Outline (length x width x height) 50" x 13" x 27.5"
Net Weight 82.5 lbs (37.5kg)

Price:
List Price: $4,399.20
Prepaid Price: $3,900.00



Call for Pricing and Availability


Gear Pump Filler


Gear pump filling machines are equipped with microcomputer-controlled chips which can control the filling time and filling flow precisely. It is widely used in the industries such as pharmacy, food, grease, daily chemical, domestic chemical, agricultural chemical and cosmetics.

These units are ideal for liquids such as: various medications, chemicals, grease, cosmetic, food and other kinds of granule-free liquid.


Features & Specifications
GPF10K
Gear Pump Filler Heavy duty stainless steel construction
110 volts/single phase/60 Hz/10 amps
List Price: $1,803.67
Prepaid Price: $1,599.00


Model Rated Voltage Power Max. Flow Tolerance Body Size (in) Body Weight
GPF10K 110V 50/60Hz 38W Single pump > 1.4L/M ±1.5% 16" x 13" x 11" 25lbs

Call for Pricing and Availability
